Page 18 of 33
3.6 Cascade Flue Components
We currently do not do cascade flue for the Thision S
Plus. If you wish to install a cascade flue system for
the Thision S Plus range, please contact a specialist
flue supplier.
Elco only supply the cascade flue header as pictured,
the flue pipe exiting the cascade flue header will need
to be sourced via a flue specialist. The air intake
header will be need to be sourced by a flue specialist.
Please see the relative boiler operation and
installation manual for the information regarding
cascade flue system lengths and diameters.
2 Boilers In-Line Cascade Flue
3 Boilers In-Line Cascade Flue
4 Boilers In-Line Cascade Flue
5 Boilers In-Line Cascade Flue
6 Boilers In-Line Cascade Flue
3 Boilers Back to Back Cascade Flue
4 Boilers Back to Back Cascade Flue
5 Boilers Back to Back Cascade Flue
6 Boilers Back to Back Cascade Flue
7 Boilers Back to Back Cascade Flue
8 Boilers Back to Back Cascade Flue
2 Boilers In-Line Cascade Flue
3 Boilers In-Line Cascade Flue
4 Boilers In-Line Cascade Flue
5 Boilers In-Line Cascade Flue
6 Boilers In-Line Cascade Flue
3 Boilers Back to Back Cascade Flue
4 Boilers Back to Back Cascade Flue
5 Boilers Back to Back Cascade Flue
6 Boilers Back to Back Cascade Flue
7 Boilers Back to Back Cascade Flue
8 Boilers Back to Back Cascade Flue
