elco THISION L PLUS User Manual

46
Installation
Electrical connection
Multi function
Function DGTO val
None 0
Heatgenshuto󰀨valve 1
Heat request 2
Alarm output 3
Flue gas damper 4
Lpg/Room Supply Fan 5
MO1 OUTPUT (0-10V)
ECU I/O Menu display parameter
MO1_LV Multi Out PWM 1
24.7.4 (Commercial Boiler);
26..32.7.4 (Commercial Boiler – Slave 1..7);
Function Function value
None 0
System pump modulator 1
DHW Pump modulator 2
Circulating pump modulator 3
BUF Filling pump modulator 4
boiler power feedback 5
MTS 1-2-3
ECU I/O Menu display parameter
MTS1 Multi In Temp 1
24.6.0 (Commercial Boiler);
26..32.6.0 (Commercial Boiler – Slave 1..7);
MTS2 Multi In Temp 2
24.6.1 (Commercial Boiler);
26..32.6.1 (Commercial Boiler – Slave 1..7);
MTS3 Multi In Temp 3
24.6.2 (Commercial Boiler);
26..32.6.2 (Commercial Boiler – Slave 1..7);
Function Function value
None 0
Commonowsensor 1
DHW storage tank bottom 2
DHW circulation sensor 3
DHW charging sensor 4
Bu󰀨erstoragetanktop 5
Bu󰀨erstoragetankbottom 6
Flue gas temp sensor 7
