0209 12
3
01106073
Page
Notice
Date
OPERATING
HANDBOOK
Service screen in Automatic mode
Service screen in Manual mode
The fi rst line of the screen displays the values for the
current use of the machine.
• The
"M" shows that you are in manual mode.
The following three values show:
• The current cylinder temperature
• The ironing speed
• The sheet counter information.
Various indications regarding the temperature of the
ironing cylinder are displayed:
• If the temperature indicator blinks, this means the
machine is preheating.
• A (-) sign indicates that the temperature of the
cylinder is below 100°C (212°F).
• The current temperature is displayed when the
temperature of the cylinder is between 101°C and
245°C (213°F and 470°F)).
Note: values 101-245°C are minimum and
maximum temperature that the electronic
programmer can display. The maximum ironing
temperature cannot reach 245°C (470°F), a
safety thermostat automatically cuts off heating
before reaching this value.
• A (+) sign indicates that the temperature of the
cylinder is above 245°C (470°F).
At this point, press one of the three keys to return to
the manual/automatic mode selection display. Use
this function to change the set temperature or ironing
speed.
The second-line displays the commands accessible
from the buttons on the panel.
Service screen in Manual mode
Service screen in automatic mode
The values for the current use of the machine are
shown on the fi rst line of the screen.
• The
"D" shows that you are in automatic mode
(DIAMMS).
The two following values show:
• The ironing speed
• The sheet counter information
In automatic mode (DIAMMS), the cylinder
temperature will not be displayed. This is managed by
the machine itself. Only the fl ashing "°C" indicator is
shown.
The second line displays the commands accessible
from the buttons on the panel.
Dx °C 2.5m/mn 000
MANU NEXT
Mx 160°C 2.0m/mn 000
DIAMMS NEXT
3. Method of use
