Instruction Manual
D103785X012
Parts
June 2017
85
Section 7 Parts77
Parts Ordering
Whenever corresponding with your Emerson sales office or Local Business Partner about this equipment, always
mention the controller serial number.
WARNING
Use only genuine Fisher replacement parts. Components that are not supplied by Emerson Automation Solutions should
not, under any circumstances, be used in any Fisher instrument. Use of components not supplied by Emerson Automation
Solutions may void your warranty, might adversely affect the performance of the instrument, and could cause personal
injury and property damage.
Parts Kits
Kit Description Part Number
1* Elastomer Spare Parts Kit (kit contains parts to
service one digital valve controller)
Standard 19B5402X012
Extreme Temperature option
(fluorosilicone elastomers) 19B5402X022
2* Small Hardware Spare Parts Kit (kit contains parts
to service one digital valve controller) 19B5403X012
3 Conversion Kit, DVC6015 to DVC6025 19B5405X012
4 Conversion Kit, DVC6025 to DVC6015 14B5072X112
5 Alignment Pin Kit
[kit contains 15 alignment pins (key 46)] 14B5072X092
6* Seal Screen Kit
[kit contains 25 seal screens (key 231)
and 25 O-rings (key 39)]
Standard and Extreme Temperature option 14B5072X182
(fluorosilicone elastomers)
Kit Description Part Number
Note
The following terminal boxes are only compatible with PWB Assembly
electronics hardware revision 2 (HW2) (key 50), as shown in figure 7‐1.
Use only with replace in-kind.
7 Terminal Box Kit
Without I/O Package
Standard Temperature (nitrile elastomers) 19B5401X142
Extreme Temperature (fluorosilicone elastomers 19B5401X152
Without I/O Package, Natural Gas Approved
Standard Temperature (nitrile elastomers) 19B5401X162
Extreme Temperature (fluorosilicone elastomers 19B5401X172
With I/O Package
Standard Temperature (nitrile elastomers) 19B5401X182
Extreme Temperature (fluorosilicone elastomers) 19B5401X192
*Recommended spare
