Emerson LC260EM1 User Manual

English
35
EN
INTRODUCTION
PREPARATION
WATCHING TV
OPTIONAL SETTING
TROUBLESHOOTING
INFORMATION
Other Specifi cations
Terminals
Antenna Input VHF / UHF / CATV 75 Ω unbalanced (F-type)
Audio Input RCA jack (L/R) x 6 500mV rms
Composite Video Input
RCA jack x 1 1 V p-p (75 Ω)
S-Video Input Mini DIN 4pin jack x 1 Y 1 V p-p (75 Ω)
C 286 mV p-p (75 Ω)
Component Video Input
RCA jack x 3 Y 1V p-p (75 Ω)
Pb/Cb 700 mV p-p (75Ω)
Pr/Cr 700 mV p-p (75Ω)
HDMI Input HDMI 19pin x 3
Coaxial Digital Audio Output
RCA jack x 1 500 mV p-p (75 Ω)
Audio Output RCA jack (L/R) x 2 500 mV rms
Remote control
Digital encoded infrared light system
Operating temperature
41 °F (5 °C) to 104 °F (40 °C)
Power requirements
120V~ AC +/- 10 %, 60 Hz +/- 0.5 %
LCD
For LC320EM1F / LC320EM1
32 inches (31.5 inches measured diagonally)
Power consumption (maximum)
145 W
Dimensions
<without base> <with base>
Width 29
15
/
16
inches (760.0 mm) 29
15
/
16
inches (760.0 mm)
Height 20
1
/
2
inches(519.3 mm) 22
3
/
16
inches (563.0 mm)
Depth 4
1
/
4
inches(107.0 mm) 9
1
/
4
inches(234.0 mm)
Weight
18.96 lbs. (8.60 kg) 20.07 lbs. (9.10 kg)
LCD
For LC260EM1
26 inches
Power consumption (maximum)
110 W
Dimensions
<without base> <with base>
Width 25
7
/
8
inches (656.0 mm) 25
7
/
8
inches (656.0 mm)
Height 17
11
/
16
inches (448.0 mm) 19
3
/
16
inches (487.0 mm)
Depth 4
7
/
16
inches(112.0 mm) 9
1
/
4
inches(234.0 mm)
Weight
14.89 lbs. (6.75 kg) 15.88 lbs. (7.20 kg)
General Specifi cations
TV format ATSC / NTSC-M TV standard
Closed caption system
§15.122 / FCC (digital CC)
§15.119 / FCC (analog CC)
Channel coverage (ATSC / NTSC)
Terrestrial DTV (ATSC)
VHF 2~13
UHF 14~51 each channel has e.g.)
2.1~2.9, 3.1~3.9, etc.
Terrestrial Analog (NTSC)
VHF 2~13
UHF 14~69
CATV 2~13, A~W,
W+1~W+94 (analog W+1~W+84),
A-5~A-1, 5A
Tuning system Channel frequency synthesized tuning
system
Channel access Direct access keyboard,
Programmable scan, and up / down
Electrical Specifi cation
Audio Output 5W, 8 Ω x 2
• Designs and specifi cations are subject to change without
notice and without our legal obligation.
• If there is a discrepancy between languages, the default
language will be English.
