12
U.L. Model No.: 42-ANT & 52-ANT
7. Hanging the Ceiling Fan
(Close-to-the-Ceiling Method with
Ceiling Cover Installed on the Motor Housing)
HANGER
BRACKET
HOOK
HOOK ON HANGER BRACKET MUST PASS THROUGH SCREW HOLE
IN CEILING COVER, INSIDE OF BRACKET TO OUTSIDE OF BRACKET
CEILING
COVER
Figure 15
7.1
C
arefully lift the fan assembly up to the hanger bracket.
Pass the hook on the hanger bracket (Figure 15)
through one of the screw holes (not the slots) in the
ceiling cover (Figure 15).
The hook must pass from the inside of the ceiling cover
to the outside. The hook will hold the fan assembly
while connecting the wiring.
The hook must pass through the screw hole in the
ceiling cover from the inside to the outside. Any other
hanging method may cause the hook to break and the
fan to fall.
WARNING
!
To Next Page
