19
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: 42-ANT & 52-ANT
Do not use water when cleaning your ceiling fan.
It could damage the motor or the blades and create the
possibility of an electrical shock.
WARNING
!
IMPORTANT CARE INSTRUCTIONS
for your Ceiling Fan
Periodic cleaning of your new ceiling fan is the only
maintenance that is needed.
When cleaning, use only a soft brush or lint free cloth to
avoid scratching the finish.
Abrasive cleaning agents are not required and should
be avoided to prevent damage to finish.
14. Maintenance
13.1
Restore electrical power to the outlet box by turning the
electricity on at the main fuse box.
Check the operation of the fan by gently pulling on the
light switch pull chain.
Your fan is shipped from the factory with the reversing
switch positioned to circulate air downward. If airflow is
desired in opposite direction, turn the fan off and wait
for the blades to stop turning, then slide the reversing
switch to the opposite position, and turn the fan on
again. (Figure 31).
The fan blades will turn in the opposite direction and
reverse the airflow.
Reverse Switch Information
Season Rotation Direction Switch Position
Summer Counter-Clockwise Up
Winter Clockwise Down
13.2
Your fan model is equipped with a 4-position,
3-speed pull chain switch (Figure 32). The operating
sequence is as follows:
Three-Speed
1st Pull—HIGH
2nd Pull—Medium
3rd Pull—Low
4th Pull—OFF
13. Using Your Ceiling Fan
CHAIN
COUPLER
WOODEN PENDANT
3-SPEED
SWITCH
PULL CHAIN
LIGHT
FIXTURE
PULL CHAIN
WOODEN
PENDANT
Figure 32
Figure 31
