Loading Originals
Follow the instructions here to load your originals into the product.
Note: The illustrations are for reference only. Although they may differ slightly from the actual product,
the steps are the same unless otherwise noted.
Scanner Positions
Loading Originals in the Input Tray
Loading Large Originals
Loading Long Paper
Loading Booklets (DS-C490)
Loading Passports
Loading Multiple Sizes of Originals in the Input Tray
Loading Plastic and Laminated Cards in the Input Tray
Loading Special Originals
Scanner Positions
Your product uses two different positions for scanning, depending on the type of original being scanned.
The table below shows the scanner position used for various types of originals.
For details on how to change the scanner position, see the link at the end of this section.
Scanner Position Description Supported Originals
Vertical path
position
Use the vertical path position for
scanning thin paper, receipts, or multiple
sheets of standard-size originals.
Scanned originals are ejected from the
output tray at the top of the scanner.
• Standard size originals up to this size:
Letter (8.5 × 11 inches
[216 × 279 mm]) or A4 (8.3 × 11.7
inches [210 × 297 mm])
• Thin paper (40 g/m2)
• Receipts less than 15.5 inches
(393.7 mm) in length
• Business cards
• Mixture of originals
