Epson EB-S05 User Manual

Projector Network Settings - Network Menu
109
a
Once you have connected your projector to your network, you can
select projector settings and control projection using a compatible Web
browser. This allows you to access the projector remotely.
gg Related Links
• "Network Menu - Screen Mirroring Settings" p.109
• "Network Menu - Basic Menu" p.110
• "Network Menu - Wireless LAN Menu" p.111
• "Network Menu - Notifications Menu" p.112
• "Network Menu - Others Menu" p.113
• "Network Menu - Reset Menu" p.114
• "Selecting Password Security Types" p.74
Network Menu - Screen Mirroring Settings
Settings on the Screen Mirroring Settings menu let you select the Screen
Mirroring settings (EB‑U42).
s Network > Screen Mirroring Settings
Setting Options Description
Display Name Up to 32
alphanumeric
characters
Enter a name to identify the projector
when searching for the projector using
the screen mirroring feature.
Setting Options Description
Operation Mode Basic
Extended
Select Extended to connect with
advanced options.
Basic Wireless LAN Sys. Sets the communication method between
the projector and the mobile device.
You can select the following methods:
• 802.11a/g/n/ac
• 802.11a/g/n
• 802.11g/n
The available methods vary depending
on countries and regions.
Adjust Image
Quality
Adjusts the screen mirroring
speed/quality.
When you want to increase image
quality, select a small number. When you
want to increase processing speed, select
a large number.
Connection Mode Selects the type of WPS (Wi-Fi Protected
Setup) when you connect to the network
wirelessly. Select PIN to improve the
connection security. If your mobile
device supports only the PBC
connection, select PIN/PBC.
Available when you have set Operation
Mode to Basic.
Extended Available when you have set Operation
Mode to Extended.
Meeting Mode Selects the type of meeting.
• Interruptions OK: lets you connect to
another mobile device during Screen
Mirroring projection.
• No Interruptions: lets you exclusively
connect to one device.
Channel Selects the wireless channel used by
Screen Mirroring.

Epson EB-S05 Specifications

General

Matrix size	0.55 \
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	1.77 - 2.4 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Screen size compatibility	30 - 350 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	1985 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Color modes (2D)	Cinema, Dynamic
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
Focus	Manual
Throw ratio	1.45 - 1.96:1
Zoom capability	Yes
Fixed focal length	16.7 mm
Focal length range	- mm
Aperture range (F-F)	1.44 - 1.44
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	282 W
Power consumption (economy mode)	203 W
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Ethernet LAN (RJ-45) ports	0
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
HDMI connector type	Full-size
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 2.0 Type-B ports quantity	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Market positioning	Presentation
Cable lock slot type	Kensington
RMS rated power	2 W
Pallet width	800 mm
Pallet height	3440 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet layer	6 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2400 g
Package depth	375 mm
Package width	145 mm
Package height	335 mm
Package weight	3.46 g
