Epson EB-S05 User Manual

Projecting Two Images Simultaneously
55
c
To select an input source for the other image, select the Source setting,
press [Enter], select the input source, select Execute, and press [Enter].
a
• You can only select input sources that can be combined.
• While using the split screen feature, the Source screen appears
when you change the input source from the remote control.
d
To switch images, select Swap Screens and press [Enter].
The projected images on the left and right are swapped.
e
To enlarge one image while reducing the other image, select Screen
Size, press [Enter], select a size, and press [Enter]. To exit the menu,
press [Menu].
a
Depending on the video input signals, the images may not
appear at the same size even if you select Equal.
f
To select the audio, select Audio Source, press [Enter], select an audio
option, and press [Enter]. To exit the menu, press [Menu].
a
Select Auto to hear audio from the largest screen or the left
screen.
g
To align the projected images, select Align, press [Enter], select the
setting, and press [Enter] again. To exit the menu, press [Menu].
h
To exit the split screen feature, press [Split] or [Esc].
gg Related Links
• "Unsupported Input Source Combinations for Split Screen Projection" p.55
• "Split Screen Projection Restrictions" p.56
Unsupported Input Source Combinations for Split
Screen Projection
These input source combinations cannot be projected on a split screen.

Epson EB-S05 Specifications

General

Matrix size	0.55 \
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	1.77 - 2.4 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Screen size compatibility	30 - 350 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	1985 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Color modes (2D)	Cinema, Dynamic
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
Focus	Manual
Throw ratio	1.45 - 1.96:1
Zoom capability	Yes
Fixed focal length	16.7 mm
Focal length range	- mm
Aperture range (F-F)	1.44 - 1.44
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	282 W
Power consumption (economy mode)	203 W
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Ethernet LAN (RJ-45) ports	0
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
HDMI connector type	Full-size
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 2.0 Type-B ports quantity	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Market positioning	Presentation
Cable lock slot type	Kensington
RMS rated power	2 W
Pallet width	800 mm
Pallet height	3440 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet layer	6 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2400 g
Package depth	375 mm
Package width	145 mm
Package height	335 mm
Package weight	3.46 g
