Epson EB-S05 User Manual

Solving Image or Sound Problems
140
Check the solutions in these sections if you have any problems with projected
images or sound.
gg Related Links
• "Solutions When No Image Appears" p.140
• "Solutions When Image is Incorrect Using the USB Display Function" p.141
• "Solutions When "No Signal" Message Appears" p.141
• "Solutions When "Not Supported" Message Appears" p.142
• "Solutions When Only a Partial Image Appears" p.142
• "Solutions When the Image is not Rectangular" p.142
• "Solutions When the Image Contains Noise or Static" p.143
• "Solutions When the Image is Fuzzy or Blurry" p.143
• "Solutions When the Image Brightness or Colors are Incorrect" p.144
• "Solutions to Sound Problems" p.144
• "Solutions When Image File Names are not Displayed Correctly in PC Free"
p.145
Solutions When No Image Appears
If no image appears, try the following solutions:
• Press the power button to turn the power on.
• Make sure the lens cover is open all the way.
• Press the [A/V Mute] button on the remote control to see if the image was
temporarily turned off.
• Make sure all necessary cables are securely connected and the power is on
for the projector and connected video sources.
• Make sure the image being projected is not completely black (only when
projecting computer images).
• If the projector does not respond when you press the [Home] button on the
control panel or remote control, an internal error may have occurred in the
projector. Contact Epson for help.
• Make sure the projector's menu settings are correct.
• Press the projector's power button to wake it from standby or sleep mode.
Also, check if the connected computer is in sleep mode or displaying a
blank screen saver.
• Check the settings on the projector's Signal menu to make sure they are
correct for the current video source.
• Adjust the Brightness setting in the projector's Image menu.
• Select Normal as the Power Consumption setting.
s ECO > Power Consumption
• Check the Display setting in the projector's Extended menu to make sure
Messages is set to On.
• If the projector does not respond when you press the control panel buttons,
the buttons may be locked for security. Unlock the buttons in the Control
Panel Lock setting in the projector's Settings menu or use the remote
control to turn on the projector.
s Settings > Lock Setting > Control Panel Lock
• If the projector does not respond when you press buttons on the remote
control, make sure the remote receivers are turned on.
• For images projected with Windows Media Center, reduce the screen size
from full screen mode.
• For images projected from applications using Windows DirectX, turn off
DirectX functions.
• The projector may not be able to project copyrighted videos that you play
back on a computer. For more details, see the manual supplied with the
computer.
gg Related Links
• "Input Signal Settings - Signal Menu" p.102
• "Image Quality Settings - Image Menu" p.101
• "Projector Setup Settings - ECO Menu" p.115
• "Projector Setup Settings - Extended Menu" p.106
• "Unlocking the Projector's Buttons" p.76

Epson EB-S05 Specifications

General

Matrix size	0.55 \
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	1.77 - 2.4 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Screen size compatibility	30 - 350 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	1985 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Color modes (2D)	Cinema, Dynamic
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
Focus	Manual
Throw ratio	1.45 - 1.96:1
Zoom capability	Yes
Fixed focal length	16.7 mm
Focal length range	- mm
Aperture range (F-F)	1.44 - 1.44
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	282 W
Power consumption (economy mode)	203 W
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Ethernet LAN (RJ-45) ports	0
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
HDMI connector type	Full-size
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 2.0 Type-B ports quantity	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Market positioning	Presentation
Cable lock slot type	Kensington
RMS rated power	2 W
Pallet width	800 mm
Pallet height	3440 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet layer	6 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2400 g
Package depth	375 mm
Package width	145 mm
Package height	335 mm
Package weight	3.46 g
