a
If not all of the files and folders are displayed on the current
screen, press the [
]
] button on the remote control, or position
the cursor on Next Page at the bottom of the screen and press
the [
] button.
To return to the previous screen, press the [[] button on the
remote control, or position the cursor on Previous Page at the
top of the screen and press the [
] button.
b
Press the [ ] button.
The selected image is displayed.
When a folder is selected, the files in the selected folder are
displayed. To return to the previous screen, position the cursor on
Back to Top and press the [
] button.
Rotating images
You can rotate the played images in 90˚ increments. The rotating function
is also available during Slideshow.
a
Play images, or run Slideshow.
b
While projecting, press the [ ] or [ ] button.
Stopping Slideshow
To close Slideshow, disconnect the USB device from the USB port on the
projector. For digital cameras, hard disks, and so on, turn off the power to
the device and then remove.
Projecting the selected image
Attention
Do not disconnect the USB storage device while it is being accessed.
Slideshow may not operate correctly.
a
Start Slideshow.
The file list screen is displayed.
s "Starting Slideshow" p.47
Projection Functions
49

Table of Contents

Other manuals for Epson EB-X11

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-X11 and is the answer not in the manual?

Epson EB-X11 Specifications

General IconGeneral
Matrix size0.55 \
Projection distance1.8 - 2.17 m
Projection technologyLCD
Contrast ratio (typical)3000:1
Screen size compatibility30 - 300 \
Projector native resolutionXGA (1024x768)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)2080 ANSI lumens
Aspect ratio4:3
RS-232 ports1
Dimensions (WxDxH)295 x 228 x 77 mm
Connectivity technologyWired
F-number (relative aperture)1.58
FocusManual
Offset8:1 %
Throw ratio1.48 - 1.77:1
Optical zoom1.2 x
Focal length range16.9 - 20.28 mm
Lamp typeUHE
Lamp power200 W
Light source typeLamp
Service life of light source4000 h
Service life of light source (economic mode)5000 h
DVI portNo
USB connector typeUSB Type-A, USB Type-B
HDMI ports quantity0
Serial interface typeRS-232
USB 2.0 ports quantity2
Full HDYes
Supported video modes1080i
Supported graphics resolutions1024 x 768 (XGA), 1920 x 1080 (HD 1080)
RMS rated power2 W
Image formats supportedBMP, GIF, JPG, PNG
Noise level37 dB
Preset modesCinema, Dynamic, Presentation, sRGB
Country of originChina
Noise level (economic mode)29 dB
Product typeStandard throw projector
Product colorWhite
Cable lock slot typeKensington
Power consumption (standby)0.47 W
Power consumption (typical)270 W
Pallet width800 mm
Pallet height2178 mm
Pallet length1200 mm
Pallet width (UK)1000 mm
Quantity per pack1 pc(s)
Quantity per pallet78 pc(s)
Quantity per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth228 mm
Width295 mm
Height77 mm
Weight2300 g
Package depth358 mm
Package width357 mm
Package height156 mm
Package weight3500 g
