71
Specifications
* The USB interface complies with the USB 1.1 standard.
The USB connector is not guaranteed to operate correctly with all USB-
compatible devices.
If you use it when it is tilted more than 30°, it could be damaged and cause
an accident.
Product name Multimedia Projector EMP-S4
Dimensions 327 (W) × 87 (H) × 247 (D) mm (not including feet)
Panel size 0.5 inches
Display method Polysilicon TFT active matrix
Resolution SVGAg 480,000 pixels (800 (W) × 600 (H) dots) × 3
Focus adjustment Manual
Zoom adjustment Electronic (approx. 1:1.35)
Lamp
(light source)
UHE lamp, 170 W, Model No.: ELPLP36
Max. audio output 1W monaural
Speaker 1
Power supply 100 to 240VAC 50/60Hz 2.9 to 1.2A
Power Consumption
Operating: 250W(100 to 120V area)
240W(220 to 240V area)
Standby : 5W(100 to 120V area)
6W(220 to 240V area)
Operating altitude 0 to 2286 m (0 to 7500 ft)
Operating
temperature
+5 to +35ºC (41 to 95ºF ) (No condensation)
Storage
temperature
-10 to +60ºC (14 to 140ºF ) (No condensation)
Weight Approx. 2.6 kg
Connectors Computer 1 Mini D-Sub 15-pin (female)
Blue
S-Video 1 Mini DIN 4-pin
Video 1 RCA pin jack
Audio Input 1 RCA pin jack×2 (L,R)
USB* 1 USB connector (B series)
Monitor Out 1 Mini D-Sub 15-pin (female)
Black
Angle of tilt
Safety standards
USA
UL60950-1
Canada
CSA C22.2 No.60950-1
EU
The Low Voltage Directive
(73/23/EEC)
IEC/EN60950-1
EMC standards
USA
FCC Part 15B Class B (DoC)
Canada
ICES-003 Class B
EU
The EMC Directive
(89/336/EEC)
EN55022, Class B
EN55024
IEC/EN61000-3-2
IEC/EN61000-3-3
Australia/New Zealand
AS/NZS CISPR 22:2002 Class B
Pixelworks DNX
TM
ICs are used in this Projector.
0 to 30° 0 to 30°
