Epson L110 Service Manual

L350/L300/L355/L210/L110 Series Revision B
Confidential
Disassembly/Reassembly Disassembly Flowchart (Printhead/Main Board) 39
2.2.2 Disassembly Flowchart (Printhead/Main Board)
Flowchart 2-8. Disassembly Flowchart (Printhead/Main Board)
 Printhead
 Main Board
Housing Rear
1
4
(p 40)
S4
 Scanner FFC (CN11)
 Ferrite core
 FFC/Cable* 10
 FFC/Cable* 11
 FFC/Cable* 11
Main Board
2
---
(p 42) (p 49)
(p 52)
S6 S7
Hinge
1
---
---
S4
Housing Right
---
3
(p 40)
Scanner Unit
1
2
(p 52)
S4
Housing Left
1
5
(p 40)
S4
Paper Support
Assy
---
2
---
 FFC/Cable* 9
Hopper
---
2
(p 52)
FFC Holder MB
1
2
---
S7
Shield Plate
3
---
---
S6 S13
Main Board
1
---
(p 42) (p 49)
(p 52)
S7
 FFC/Cable* 10
Shield Plate
3
---
---
S6 S13
The Printhead can be replaced without removing the Scanner Unit. However, the working
space for replacement is narrow and dark. Therefore, if you find it difficult to work,
remove the Scanner Unit first before replacement.
FFC/cable list
No. FFC/Cable
9 Disconnect the Panel FFC (CN2), and remove the ferrite core.
10
Remove/disconnect the following.
 FFC (CN102, CN6)
 PF Motor cable (CN13)
 PS Unit cable (CN501)
11 Remove/disconnect all FFCs/cables.
L350/L355/L210 Series
L355 Series specific parts/unit
L350/L355/L210 Series specific
parts/unit
L300/L110 Series specific
parts/unit
L210/L110 Series specific
parts/unit
Common parts/unit
 Ink Supply Tube Assy
Adapter Cover
1
6
---
S17
Holder Board
---
2
---
 CR Encoder FFC
Printhead
3
---
(p 43) (p 52)
S11
FFC Cover Outer
---
1
(p 42)
 Head FFC
Adapter
---
1
(p 47)
L300/L110 Series
Housing Upper
Assy
4
3
(p 48)
S5
FFC Cover Outer
---
1
(p 42)
Printhead
3
---
(p 43) (p 52)
S11
 CR Encoder FFC
Housing Upper
Assy
4
3
(p 48)
S5
Housing Front
3
2
---
S6
Paper Support
Assy
---
2
---
Hopper
---
2
(p 52)
PF Motor Cover
---
2
---
L300/L110 Series
 Ink Supply Tube Assy
Adapter Cover
1
6
---
S17
Adapter
---
1
(p 47)
Holder Board
---
2
---
 Head FFC
L350/L355/L210 Series
Screw type/torque list
Symbol Screw Type Torque
C.B.P-TITE SCREW 2.5x8 F/ZN-3C 3 ± 1 kgf·cm
C.B.P-TITE SCREW 2x8 F/ZN-3C 4 ± 1 kgf·cm
C.B.P-TITE SCREW 3x10 F/ZN-3C 5
± 1 kgf·cm
C.B.P-TITE SCREW 3x10 F/ZN-3C 6 ± 1 kgf·cm
C.B.S-TITE SCREW 3x6 F/ZN-3C 4
± 0.5 kgf·cm
C.B.S-TITE SCREW 3x6 F/ZN-3C 6 ± 1 kgf·cm
C.B.S-TITE SCREW 3x8 F/ZN-3C 6
± 1 kgf·cm
C.P SCREW 3x4 F/ZN-3C 4 ± 1 kgf·cm
C.P.F.B-TITE SCREW 2x8 F/ZN-3C 4
± 1 kgf·cm
C.P.S-TITE (P2) SCREW 3x6 F/ZN-3C 7 ± 1 kgf·cm
C.B.P-TITE SCREW 2.5x8 F/ZN-3C 5
± 0.5 kgf·cm
C.P SCREW 2.6x3 F/ZN-3C 4 ± 0.5 kgf·cm
C.B.S-TITE SCREW 3x4 F/ZN-3C 2
± 0.5 kgf·cm
C.B.P-TITE SCREW 2x8 F/ZN 2 ± 0.5 kgf·cm
C.B.P-TITE SCREW 2x8 F/ZN 25
± 0.5 kgf·cm
C.B.P-TITE SCREW 3x6 F/ZN 4 ± 1 kgf·cm
C.B.P-TITE SCREW 2.5x8 F/ZN 6
± 1 kgf·cm
C.B.P-TITE SCREW 2.6x5 F/ZN 3 ± 0.5 kgf·cm
C.B.P-TITE SCREW 3x6 F/ZN 3
± 0.5 kgf·cm
S1
S2
S3
S4
S5
S6
S7
S8
S9
S10
S11
S12
S13
S14
S15
S16
S17
S18
S19

Epson L110 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Maximum resolution	5760 x 1440 DPI
Print speed (color, draft quality, A4/US Letter)	15 ppm
Print speed (black, normal quality, A4/US Letter)	27 ppm
Sound pressure level (printing)	38 dB
Paper input type	Paper tray
Total input capacity	50 sheets
Total output capacity	30 sheets
Envelopes sizes	10, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Coated paper, Glossy paper, Matte paper, Photo paper, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Photo paper sizes (imperial)	4x6, 5x7, 8x10 \
Maximum ISO A-series paper size	A4
Ethernet LAN	No
Standard interfaces	USB 2.0
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	10 W
Sustainability certificates	ENERGY STAR
Product color	Black
Market positioning	Home & office

Weight and Dimensions

Depth	222 mm
Width	472 mm
Height	130 mm
Weight	2700 g
