Epson TM-S1000 User Manual

CaptureOne User’s Manual 13
English
Pulling Out the Guides
Pocket Guide
CAUTION:
Be sure to pull out the pocket guide far enough to accommodate the
documents stored in the guide before using the scanner. Otherwise a
paper jam may occur.
ASF/SF Guide
Feeding paper using the ASF/SF guide allows you to insert documents
straight. Pull out the ASF/SF guide if necessary.
Pocket guide
ASF/SF guide

Epson TM-S1000 Specifications

General

Film scanning	No
Grayscale levels	256
Input color depth	- bit
Maximum scan size	120 x 235 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
Scan media weight	60 - 120 g/m²
Dimensions (WxDxH)	160 x 355 x 176 mm
Standard media sizes	Length: 120 mm - 235 mm (approx 4.8 in - 9 in), Height: 68mm - 120 mm (approx 2.7 in - 4.8 in), Thickness: 0.075 x 0.2 mm (approx 0.003 in - 0.008 in), Weight: 60 - 120 g/m2 (approx 16lb - 32lb)

Weight and Dimensions

Depth	355 mm
Width	160 mm
Height	176 mm
Weight	4000 g
