10 • Maintenance and servicing
48 / 62
80116-276_V24169
2022-01
Instrument recognition FiAPC socket
Testing and measuring equipment
Instrument recognition
via EEPROM
Test setup
• The test specimen is connected to the power supply via a VIO electro-
surgical unit.
Test procedure
1. Connect test adapter to the FiAPC socket on the test specimen. The
test specimen must indicate instrument recognition with a message.
The setting on the VIO HF surgical unit must switch to APC socket.
2. Remove test adapter. The test specimen must recognize and indicate
removal of the adapter.
Instrument recognition multifunction sockets
This test can only be performed with the following combination: APC 2 +
VIO 300
D.
Testing and measuring equipment
Instrument recognition via
resistance
Currently not available.
Instrument recognition
via EEPROM
Test setup
• The test specimen is connected to the power supply via a VIO 300 D.
Test procedure
1. For an MF socket: Connect the measuring cable (art. no. 20100-152)
to the MF socket of the test specimen. The test specimen must dis-
play instrument detection with an advisory message. The setting for
COAG mode must switch to BiClamp.
2. For an MF-2 socket: Connect the measuring cable (art. no. 20100-
189) to the MF-2 socket of the test specimen. The test specimen
must display instrument detection with an advisory message. The
setting for COAG mode must switch to BiClamp.
Erbe Art. No. Description
20100-175 FiAPC test adapter
Erbe Art. No. Description
20100-152 BiClamp measuring cable (only if a MF
socket is available)
20100-189 BiClamp MF-2 measuring cable (only if a
MF-2 socket is available)
