53 / 62
10 • Maintenance and servicing
80116-276_V24169
2022-01
Test procedure
1. Set test specimen to:
FORCED APC, 80 watts
Flow 1.8 l/min
2. With APC sockets: Point the VIO APC handpiece at the metal panel
with viscose sponge without touching the NE device. Activate the
handpiece. The argon must ignite.
3. With FiAPC sockets: Point the FiAPC probe at the metal panel with
viscose sponge without touching the NE device. Activate the probe
with the footswitch. The argon must ignite.
HF socket performance test
The performance test on an additional HF socket with which the APC 2 may
be provided is dependent on the VIO electrosurgical unit (VIO
D or VIO S) to
which the APC 2 is connected. It is therefore only described in the service
manual for the relevant VIO electrosurgical unit.
Monopolar / MF socket 1. With APC 2 + VIO D: Perform tests as described in the chapter "Fin-
gerswitch activation", Service Manual VIO D.
2. With APC 2 + VIO S: Perform tests as described in the chapter "Finger-
switch activation", Service Manual VIO S.
Bipolar socket 1. With APC 2 + VIO D: Perform tests as described in the chapter "Auto-
matic start mode", Service Manual VIO D.
2. With APC 2 + VIO S: Perform tests as described in the chapter "Auto-
matic start mode", Service Manual VIO S.
WARNING! Risk of injury due to electrically conductive objects and high voltage. Do
not touch any electrically conductive objects with the instrument when
it is activated. Under no circumstances should you touch the beam.
