17
Table 1 Multimaster 260 Specications
2.1 GENERAL
This manual has been prepared for experienced welders. Do
NOT permit untrained persons to install, operate or maintain
this equipment. Do NOT attempt to install or operate this
equipment until you have read and fully understand these
instructions.
This manual is intended for use in familiarizing person nel with
the design and operation of this equipment. All information
presented here should be read careful ly before installing and
using this equipment.
2.2 RECEIVING-HANDLING
Upon receipt of this equipment, clean all packing material
from around the unit and immediately inspect for any dam-
age that may have occurred during shipment. Any claims
for loss or damage occurring in transit must be led with
the carrier. The carrier will furnish a copy of the bill of lading
and the freight bill on request, if the need to le a damage
claim arises.
When requesting information regarding this equipment,
make sure that you include product name, part num ber, and
serial number.
2.3 DESCRIPTION
The Multimaster 260 is a DC welding system designed for
Mig (GMAW), Tig (GTAW) or Stick (SMAW) welding. In the Mig
mode this unit is capable of operating with short arc or spray
arc transfer and handles both solid wires and tubular cored
wires. This unit is suitable for carbon steel, stainless steel,
aluminum and many other alloys. It provides a power source
with built in wire feeder and undercarriage with provisions
for two gas cylinders.
2.3.1 PACKAGES
The following part numbers and descriptions are for the
Multimaster 260 as packaged with choice of gun length,
gas owmeter regulator, and primary input voltage.
Multimaster 260 Console with:
0558001519 12-ft gun Argon 208/230vac 1ph 50/60Hz.
0558001523 12-ft gun CO
2
208/230vac 1ph 50/60Hz.
0558001521 12-ft gun Argon 230/460/575vac 1ph 50/60Hz.
0558001525 12-ft gun CO
2
230/460/575vac 1ph 50/60Hz.
0558001520 15-ft gun Argon 208/230vac 1ph 50/60Hz.
0558001524 15-ft gun CO
2
208/230vac 1ph 50/60Hz.
0558001522 15-ft gun Argon 230/460/575vac 1ph 50/60Hz.
0558001526 15-ft gun CO
2
230/460/575vac 1ph 50/60Hz.
Primary Input Voltage 208 Vac 230 Vac 460 Vac 575 Vac
1 Phase 1 Phase 1 Phase 1 Phase
Primary Current
@ 260 Amp @ 27 Volt 57 Amps 52 Amps 26 Amps 20 Amps
@ 200 Amp @ 24 Volt 35 Amps 32 Amps 16 Amps 13 Amps
Duty Cycle 50% 100%
Rated DC Output 260 Amps 200 Amps
Process MIG (GMAW) TIG (GTAW) STICK (SMAW)
Output Current Range 35-300 Amps 15-300 Amps 40-300 Amps
Open Circuit Voltage (max) 39.0 Vdc 20 Vdc 70 Vdc
Wire Feed Speed Range 65-675 Inches per Minute
Dimensions Length Width Height
(with Cyl. Rack & Wheels) 42” 20” 32”
Weight (w/o Cyl.) 250 Lbs
SECTION 2 INTRODUCTION
