10
SPECIFICATIONS
1
MODEL
Item
4R(D)
(Dual Tank)
6R(S)
(Separate Tank)
Overall Length mm (in)
783 (30.8)
Overall Width mm (in)
343 (13.5)
Overall Height S·L·XL
mm (in)
Except for USA and Canada model
1,053 (41.5) · 1,180 (46.5) ·
1,307 (51.5)
1,039 (40.9) · 1,166 (45.9) ·
1,293 (50.9)
For USA and Canada model
1,067 (42.0) · 1,194 (47.0) ·
1,321 (52.0)
Transom Height S·L·XL mm (in)
435 (17.1) · 562 (22.1) · 689 (27.1)
Weight
S Kg (lb)
26.1 (57.5) 25.6 (56.4)
L Kg (lb)
26.6 (58.6) 26.1 (57.5)
XL Kg (lb)
— 26.6 (58.6)
Output kW (Hp)
4 : 2.9 (4) 6 : 4.4 (6)
Max. Operating Range rpm
4 : 4,500 - 5,500 6 :5,000 - 6,000
Idle Speed in Forward Gear rpm
1,100
Idle Speed in Neutral Gear rpm
1,300
Engine Type
4-Stroke
Number of Cylinder
1
Bore
×
Stroke mm (in)
59
×
45 (2.32
×
1.77)
Piston Displacement mL (Cu in)
123 (7.5)
Exhaust System
Through hub exhaust
Cooling System
Water cooling
Engine Lubrication
Trochoid pump
Startring System
Manual Starter
Ignition System
Ignitor
Spark Plug
NGK DCPR6E
Trim Position
6
Engine Oil
API SF, SG, SH or SJ
FCW 10W-30/40, Approx. 450 (15.2)
Gear Oil
Genuine Gear Oil or API GL5,
SAE #80-90, Approx. 195mL
Fuel
Unleaded regular gasoline : Pump posted 87 Octane
(research octane rating of 91)
Fuel Tank Capacity L (US gal)
＊
1.15 (0.30) Integral 12 (3.17) Separate
Gear Reduction Ratio
2.15 (13 : 28)
Emission Control System
Engine modification (EM)
Operator Sound Pressure
(ICOMIA 39/94) dB(A)
81.6
Hand Vibration Level
(ICOMIA 38/94) m/sec2
7.2
＊
In case of dual fuel tank system, use it together with 12L separate tank.
SPECIFICATIONS
4, 6
