17
PRE-OPERATING PREPARATIONS
5
4.
EPA approval Primer valve/hose assembly
E Q U I P P E D F O R U N I T E D
STATES AND CANADA MODEL
Evinrude adopts Primer bulb/hose as-
sembly approved by the Environment
Protection Agency (EPA).
Please use the EPA approved primer
bulb/hose assembly with the identifi-
cation mark on the fuel connector.
Be sure to use EPA approved tank
and EPA approved primer bulb/hose
assembly as a set. Confirm shapes of
EPA approved tank and regular tank.
Except for U.S. model
(regular tank)
For U.S. and Canada model
(EPA approved tank)
!
3. EPA pressurized fuel tank requirements
EQUIPPED FOR UNITED STATES
AND CANADA MODEL
The Environmental Protect ion Agency
(EPA) required portable fuel systems
portable (after January 1, 2011)and
integral (after August 1, 2011) fuel sys-
tem for use with outboard engines to
remain fully sealed (pressurized) up
to 34.4 kPa (5.0 psi). These tanks may
contain the following:
●
An air inlet that opens to allow air to
enter as the fuel is drawn out of the
tank.
●
An air outlet that opens (vents) to
the atmosphere if pressure exceeds
34.4 kPa (5.0 psi). A hissing noise
may be heard as the tank vents to
the atmosphere. This is normal.
●
When installing the fuel tank cap,
turn the cap to the right until you
hear two clicks. This signals that
the fuel cap is fully seated. A built-
in device prevents overtightening.
●
The fuel tank has a manual vent
screw which should be closed for
transportation and full open for op-
eration and cap removal.
Since sealed fuel tanks are not openly
vented, they will expand and contract
as the fuel expands and contracts
during heating and cooling cycles of
the outside air. This is normal.
*Please refer to P21-P25 when using this
fuel tank.
