37
ADJUSTMENT
9
The steering friction can be adjusted
in accordance with your preference
by turning the steering adjust bolt.
The turning force of the throttle grip
can be adjusted with a throttle adjust
screw.
ADJUSTMENT
1. Steering friction
2. Throttle grip
Steering adjustment Screw
Heavier
Lighter
Heavier
Lighter
Throttle
Adjustment
Screw
Note
The steering adjustment bolt is used to
adjust the friction load of the steering,
but not to fix the steering. Excess
tightening of the adjustment bolt may
cause damage to the swivel bracket.
!
Do not overtighten the throttle grip or
remote control tensioner or it could result
in difficulty of movement resulting in the
loss of control causing an accident and
could lead to severe injury.
