Extraflame LUISELLA User Manual

22
ENGLISH
STBY STAND-BY)
The stand-by function is used if the stove needs to be turned o immediately instead of a power modulation.
CONTROLS PROCEDURE
 Press and hold key 4.
 Press key 3 until SET appears and access with key 4.
 Press key 3 until STBY appears and access with key 4.
 Enable/disable using keys 4 and 5 and conrm with key 2.
 Press key 1 several times to exit the menu.
 DATE
 DAY
 TIME
 LNG
 CF
SEE CHAPTER: COMMISSIONING SETTINGS.
J
FOR CORRECT OPERATION, SET THERMOSTAT SHOULD BE SET IN LOU.
> SEE THE INSTALLATION CHAPTER SUPPLEMENTARY THERMOSTAT
SET SETTINGS
STBY FUNCTION SET TO ON
When the Stand-by function is active (ON), if the room temperature exceeds the SET THERMOSTAT value + DELT, the stove will switch o
after a pre-set (default) delay period, displaying STBY.
When the room temperature is lower than the SET THERMOSTAT - DELT, the stove cools down, if necessary, and then switches o.
STBY FUNCTION SET TO OFF FACTORY DEFAULT SETTING
In the event the Stand-by function is not activated (OFF), if the stove exceeds the set room temperature, it will switch to the minimum power
level, modulating and displaying MODULATION. When the room temperature is lower than the SET THERMOSTAT the stove will restart at
the set power and WORK will be displayed on the screen.
OPERATION WITH SUPPLEMENTARY THERMOSTAT OPTIONAL
STBY FUNCTION SET TO OFF FACTORY DEFAULT SETTING
In the even the Stand-by function is not activated (OFF), if the stove reaches the room temperature set on the supplementary thermostat
(closed contact), it will switch to the minimum power level and display MODULATION. When the room temperature is lower than the set value
on the supplementary thermostat (open contact), the stove will restart at the set power, and WORK will be displayed on the screen.
STBY FUNCTION SET TO ON
If the STAND-BY function is activated (ON), when the room temperature set on the supplementary thermostat is reached (closed contact), the
stove will switch o after a pre-set (default) delay period, and STBY will be displayed on the screen.
When the room temperature is lower than the supplementary thermostat (open contact), the stove cools down, if necessary, and then re-
ignites.
DELT DELTAT
This function allows you to set the delta-t for igniting and switching o the stove, used as a room temperature adjustment interval if there
is no external thermostat. The exact temperature for ignition is SET THERMOSTAT - Delta-T. The temperature for switching o is SET
THERMOSTAT + Delta-T.
The possible values for Delta-T range from: 0.5 - 5°C
CONTROLS PROCEDURE
 Press and hold key 4.
 Press key 3 until SET appears and access with key 4.
 Press key 3 until DELT appears and access with key 4.
 Adjust with keys 4-5 and 2 to conrm.
 Press key one several times to conrm and exit the menu.
