DDS
HARDWARE
DIMENSIONS
When designing and building the electrical cabinet, it is crucial to consider
the necessary space to include the main modules that will make up the
DDS system, auxiliary modules and other elements such as cables and
connectors.
INFORMATION. Be aware that the room required for the top and bottom
connectors of the units may even be up to 50 mm.
NOTE. The user can also get 3D CAD drawing of the units from FAGOR's
corporate website, http://www.fagorautomation.com. Go to the
«download» tab and select the «CAD drawings» option of the «file types»
droplist.
