Federal Signal Corporation Modulator MOD Series User Manual

9
Specications
Description, Specications, Installation, and Service Manual
Ordering Information
Contact our Federal Signal sales engineers to design a system that meets your specic
requirements. Specify speaker array model number. Each speaker array model must be
ordered with a specic corresponding UV and amplier.
Table 2 Ordering Information
Speaker Controller
1
MOD1004B
2
UV + 1 UV400
MOD2008B
2
UV + 2 UV400
MOD3012B
2
UV + 3 UV400
MOD4016B
2
UV + 4 UV400
MOD5020B
2
UV + 5 UV400
MOD6024B
2
UV + 6 UV400
MOD6032B
2
UV + 8 UV400
MOD8032B
2
UV + 8 UV400
1
Controllers available in radio, IP, and landline.
2
Add the letter C to the Modulator model name for Steel/Concrete pole mount model.
NOTE: For the standard cable length supplied with the siren see “Table 13 Number
of Wires and Cable Length per Module” on page 19. Extension cable is also
available in 10-foot increments. Mounting the UV controller farther than 100 feet is not
recommended. (Farther mounting may decrease power output.)
Specications
Table 3 General Specications
Color Weather Guard White III
Paint Type TGIC Polyester Powder Coat
Modular Horn Type Hyperbolic Flare
Frequency Response 200-2000 Hz
Horizontal Coverage 360 Degrees
Bottom (non-active) Module* Dimensions 13-1/2 x 35 inches Diameter
Input Voltage 66 V
RMS
min., 400 W max.
* The bottom module of the siren is a passive device that does not contain any drivers. Its
functional use is to complete the horn formed by the bottom and the rst active module.
The bottom module also provides a mounting solution for the optional side lights.
The following tables list each MOD model number with its specications. Each speaker
array model must be ordered with a specic corresponding UV and Amplier.
Wind load calculations are for speaker array only.
