Fender Bullet 15 DSP Service Manual

BULLET® 15 DSP
(This is the model name for warranty claims)
3
SPECIFICATIONS
Model Name: Bullet 15 DSP
Release Number: PR 241
(Not a model number)
Part Numbers (120V, 60Hz) US: 2267700020
(110V, 60Hz) TW: 2267701020
(240V, 50Hz) AUS: 2267703020
(230V, 50Hz) UK: 2267704020
(230V, 50Hz) ARG: 2267705020
(230V, 50Hz) EUR: 2267706020
(100V, 50/60Hz) JPN: 2267707020
(220V, 60Hz) ROK: 2267709020
Power Requirement: 38W
Power Output: 15W RMS into 8 ohms @ 5%THD
Nominal Input Level: 100mV for 15W into 8 ohms @ 5%THD
Impedances Input (Pre-Amp): 1M ohms
CD Input: greater than 30k ohms
Speaker Complement: One (1) 8", 8 ohm,
Fender Special Design Speaker
(P/N 0025421000)
Dimensions Height: 12.4 in (31.4 cm)
Width: 13.25 in (33.7 cm)
Depth: 7.13 in (18.1 cm)
Weight: 15 lbs (6.8 kg)
Product specifications are subject to change without notice
