BULLET® 15 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
9
PARTS LIST:
CHASSIS ASSEMBLY
(continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
- 0040992000
**CABLE ASSY PWR 5A U.K..187 TAB
- 0026528000
**CABLE ASSY PWR 230v .187 TAB
- 0036479000
**CABLE ASSY PWR AUST .187 TABS
- 0048465000
**CABLE ASSY PWR .187 100V
- 0057675000
**CORD PWR ARG .187 TABS
1 0057359000 CABLE RIBBON 16 CKT W/2 CONN
4 0051404000 STANDOFF NYLON BLK .375 @ uDSP
1 0031868000 SCRW PLASTITE 4x1/4 PHP BLX @ J3
-
*
CLAMP CABLE NYL SCRW MNT 1/4 @ 230V-240V PWR CORDS
PARTS LIST:
CABINET ASSEMBLY
(continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
12 0026571000 SCRW SMAB 8X5/8 THP NI @ CORNERS
4 0029071000 CORNER NOTCHED NICKLE (FD)
0.910
*
TOLEX "BRAVURA BLACK"
4 0029323000 FOOT RUBBER 1.0 DIA SMALL
2 0026566000 CORNER 2 HOLE w/TAB NI
0.003
*
TAPE ALUM 5" x 60 YDS
PARTS LIST:
END ITEM ASSEMBLY
(continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0025421000 SPKR 8" PF8643 (099-4808-002)
5 0029828000 SCRW PB 8x3/4 PHP ZI @ SPKR & CABLE CLAMP
1 0057262000 MANUAL OWNERS BULLET 15 DSP
1 0057254000 LABEL REAR BULLET 15 DSP
- 0057255000 LABEL REAR ROK BULLET 15 DSP
1 0029906000 NAMEPLATE FENDER GENERIC SMALL @ BAFFLE ASSY
2 0018113000 SCRW SMA 4x1/2 OHP BLX @ LOGO
2 0025395000 HANDLE CAP 1 HOLE NI (DWG 17420) @ HANDLE
1 0025883000 HANDLE SHORT NO LOGO
2 0022277000 SCRW M 10-32x1-1/2 OHP NI @ HANDLE
1 0057763000 CAB ASSY BULLET 15 DSP
1 0050711000 CAB BACK LAMTED BLK PB 3/8"
1 0040143000 GRILLE ASSY BLK/SLVR X-15 '92
4 0029677000 SCRW SMA 6x1 THP BLX @ CAB BACK
1 0022491000 CLAMP CABLE NYL SCRW MNT 5/16 @ PWR CORD & CAB
1 0022327000 WSHR FLAT 8x7/16 NI @ CABLE CLAMP
2 0029527000 WSHR FNSH 8-5/8 FLNGD BLX WX @ CAB SIDE
2 0026800000 SCRW SMAB 8x1-3/4 OHP BLX @ CAB SIDE
0.2 0029085000 VELCRO STRIP LOOP 1.5" WD BLK @ CAB BACK
0.2 0029086000 VELCRO STRIP HOOK 1.5" WD BLK @ CAB BACK
