Fender Bullet 15 DSP Service Manual

BULLET® 15 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
8
PARTS LIST: uDSP – PCB ASSEMBLY (continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0057261008 PCB ASSY uDSP BULLET 15 DSP w/EPROM
REF 0057283000 SVC DIAG COMB MICRO DSP
1
*
IC ROM BULLET 15 DSP V1.01
1
*
PCB FAB uDSP
2
*
CAP 0805 CER .001uF 25V 5%
14
*
CAP 0805 CER .01uF 25V 5%
10
*
CAP 0805 CER .1uF 25V 5%
2
*
CAP 0805 CER 22pF 25V 5%
2
*
CAP 0805 CER 750Pf 25v 5%
3
*
CAP 3528 TAN 4.7uF 16V 20%
6
*
CAP 3528 TAN 10uF 16V 20%
5
*
DIODE SMT 1N4448 SIGNAL
2
*
HDR .1 CTR 8x2 CKT SQ PIN
4
*
RES 0805 MF 1/10W 5% 0ohm
2
*
RES 0805 MF 1/10W 5% 100ohm
4
*
RES 0805 MF 1/10W 5% 750ohm
4
*
RES 0805 MF 1/10W 5% 1k
1
*
RES 0805 MF 1/10W 5% 2k
1
*
RES 0805 MF 1/10W 5% 3.3k
2
*
RES 0805 MF 1/10W 5% 4.7k
1
*
RES 0805 MF 1/10W 5% 15k
1
*
RES 0805 MF 1/10W 5% 47k
1
*
IC SMT SOCKET PLCC 44-TT
1
*
IC SMT TLC549 AD
1
*
IC SMT SRAM 64Kx16
1
*
IC SMT COUNTER 74LV4040
1
*
IC SMT HEX SCHMITT-T INV 74HC14
1
*
IC SMT VREG +3.3V LM1117
1
*
IC SMT CODEC TLC320AD77C
1
*
IC SMT DSP TMS320VC5402PGE
1
*
IC SMT VREG +1.8V 150mA TPS76318
1
*
IC SMT RESET 5V MC34064D-5
1
*
XTAL 20MHz HC49SD
PARTS LIST: CHASSIS ASSEMBLY
(continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1
*
CHASSIS BULLET 15 DSP AMP
1
*
CLAMP CABLE NYL SCRW MNT 5/16 @ 100V-120V PWR CORDS
- 0041775000
**XFMR PWR EXPORT 100v
100V XFMR
1 0025413000
**XFMR PWR F1158UC MEX AMPS/BRNC
120V XFMR
- 0031634000
**XFMR PWR FD15 230v
220V-240V XFMR
1 0025935000
**SWITCH DPST .187 TAB (DOM)
POWER SWITCH, ALL MODELS
6 0053986000 KNOB RTRY SS W/CHR INSERT @ R13 R20 R24 R33-35
1 0057256000 KNOB RTRY ARROW W/CHR INS @ R65
5 0026459000 WSHR FLAT 6x3/8 ZI @ XFMRS, HEATSINK, PWR CORD
5 0028684000 SCRW SMB 6x3/8 PH PHS BLX @ XFMRS, HEATSINK, PWR CORD
2 0053479000 NUT HEX 7/16 20X1/8 NI @J1-2
2 0053480000 WASHER FLAT .442 X.692 NI @J1-2
1 0038900000 SCRW TF 6-32X1/4 PHP ZI @ GND
1 0048377000
**FUSE QA 20mm X 5mm 250V .5A
100V-120V FUSE
- 0020781000
**FUSE QA 20mmx5mm 250v .25A
220V-240V FUSE
1
*
PANEL FRONT BULLET 15 DSP
1 0051330000
**CABLE ASSY 120V 6 FT
