Fender Bullet 15 DSP Service Manual

BULLET® 15 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
6
PARTS LIST: MAIN – PCB ASSEMBLY (continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0057257004 PCB ASSY BULLET 15 DSP
1
* **PCB FAB BULLET 15 DSP
1
*
HEATSINK BULLET 15 DSP
REF 0057259000 SERV. DIA. COMB. BULLET 15 DSP
1
*
CAP AE AX 22uF 35V 20% C38
1
*
CAP AE AX 4.7uF 50V 20% C25
3
*
CAP AE RDL .47uF 50V 20% C12-13 C27
2
*
CAP AE RDL 1uF 50V 20% C26 C51
2
*
CAP AE RDL 2.2uF 50V 20% C6 C24
2
*
CAP AE RDL 2200uF 35V 20% C33-34
3
*
CAP AE RDL 22uF 50V 20% C7 CC48-49
2
*
CAP AE RDL 47uF 50V 20% C35-36
2
*
CAP CD 120pF 500V 5% C54-55
1
*
CAP CA 100pF 100V 5% C21
3
*
CAP CA 220pF 100V 5% C46 C52-53
1
*
CAP CA 33pF 50V 5% C20
2
*
CAP CA 470pF 50V 5% C11 C22
1
*
CAP CA 47pF 100V 5% C3
3
*
CAP CA 560pF 50V 5% C14 C29 C32
1
*
CAP CA 68pF 100V 5% C45
1
***CAP MPF .1uF 250VAC 20%
C50
9
*
CAP MPF .1uF 63V 10% C23 C37 C39-44 C47
2
*
CAP MPF .33uF 63V 10% C30-31
1
*
CAP PFF RDL .0022uF 100V 10% C5
1
*
CAP PFF RDL .0033uF 100V 10% C17
3
*
CAP PFF RDL .0047uF 100V 10% C1-2 C18
1
*
CAP PFF RDL .015uF 100V 10% C4
2
*
CAP PFF RDL .022uF 100V 10% C15-16
2
*
CAP PFF RDL .033uF 100V 10% C9-10
3
*
CAP PFF RDL .047uF 100V 10% C8 C19 C28
3
*
CONTROL 100K 30C SNAP IN R20 R24 R34
1
*
CONTROL 10KB R65
1
*
CONTROL 250K 30C R35
1
*
CONTROL 50KB SNAP IN R33
1
*
CONTROL SNAPIN 50K 15A R13
7
*
DIODE 1N4003 D5-6 D10-13 D17
7
*
DIODE 1N4448 SIGNAL D3-4 D7-9 D18-19
2
*
DIODE ZEN 1n4744a 15v 1w 5% D14-15
1
*
HEADER .1 8x2 P8
2
*
IC DUAL OP AMP TL072 U2-3
4
*
IC DUAL OPAMP PC4560 U1 U4 U6 U8
1
*
IC OP AMP PWR TDA2050V U5
1
*
IC REGULATOR +5V MC7805CT U7
1
*
JACK MONO R/A J1
1
*
JACK PHONO DUAL PC MTG J3
1
*
JACK STEREO R/A W/SL J2
