BULLET® 15 DSP
(This is the model name for warranty claims)
4
SERVICE NOTES
1. CHASSIS REMOVAL is accomplished by first
removing four (4) screws from the Rear Cabi-
net Panel and two (2) screws from the top of
the Cabinet; detach the speaker wires from the
speaker and then slide the Chassis toward the
rear of the Cabinet.
2. uDSP PCB ASSEMBLY REMOVAL is accom-
plished by disconnecting the Ribbon cable on
the uDSP PCB Assembly, releasing the tabs on
each of the plastic Stand-offs which the uDSP
PCB Assembly is mounted. Removal of the
uDSP PCB Assembly may be necessary should
any of the Digital Effects operate improperly.
3. BULLET 15 DSP MAIN PCB REMOVAL is ac-
complished by removing the following items: All
Knobs, one (1) screw at the CD Input Jack, two
(2) nuts and washers at the Input and Head-
phone Jacks, two (2) screws at the Heatsink
which attaches to the Chassis. Desolder the
Transformer Leads at P1, P4, P5, P6 and P7.
Disconnect the Yellow and Black wires at the
Power Switch leading from P2 and P3. Discon-
nect the Ribbon Cable at P8.
PCB EXCHANGE POLICY
Parts marked with a single asterisk (
*
) in the Part
Lists (starting on page 9) are not field replaceable.
If a failure due to one of these components is de-
tected, please contact the Fender® Dealer
Customer Service Department to order the com-
plete PCB Assembly.
