Fermax SMILE 3.5” Monitor User Manual

Page 8
SMILE VDSSMILE VDS
SMILE VDSSMILE VDS
SMILE VDS
SMILE VDSSMILE VDS
SMILE VDSSMILE VDS
SMILE VDS
L
+
-
+F2
T
+ A
L-F1 CT
VMMVMV
AUX
75 Ohm
COAX
• Connection Terminals:
+, -: 18 Vdc power supply.
L: data bus.
F1, F2: additional functions. See programming chapter.
T, -: call button connection for residential door (P1)
+A, -: call extension connection ref. 2040, light and bell
activator ref. 2438, etc...
• Video terminals:
V: live
M: mesh
CT: camera Activation (12 Vdc).
VAUX: auxiliary video input (CCTV
camera connection).
Connection
Monitor Connector
P1
2 OUTPUTS VIDEO DISTRIBUTOR
DISTRIBUIDOR VIDEO 2 SALIDAS
V
5
V
1
M
+18
75
M
R1
34
+
V
2
REF.2448
6
VM M
(-)
L
+
-
R
+F2
T
+A
L-F1 CT
VMMVMV
AUX
75 Ohm
COAX
P1
