❒ replace bulb F fig. 225, releasing it
from the side contacts and making
sure that the new bulb is correctly
locked between these contacts;
❒ close protective flap E fig. 225 and
refit roof light D fig. 224 in its
housing, making sure that it locks
into place.
.
REPLACING FUSES
GENERAL INFORMATION
46)
170) 171) 172) 173)
Fuses protect the electrical system:
they intervene (blow) in the event of a
fault or improper action on the system.
When a device does not work, check
the condition of its fuse: the filament
A fig. 226 must be intact. If it is not,
replace the blown fuse with another
having the same amperage (same
colour).
B intact fuse.
C fuse with damaged filament.
222
F1A0208
223
F1A0209
224
F1A0210
225
F1A0211
226
F1A0212
222
IN AN EMERGENCY
