ADDITIONAL
HEATER
(for versions/markets, where provided)
On some versions, an additional heater
is also present beneath the driver's
seat. The fan for this heater is operated
by means of the button F located on
the control panel fig. 53.
INDEPENDENT
ADDITIONAL
HEATER
(for versions/markets, where provided)
The vehicle is available, on request,
with two different independent heaters:
one fully automatic, the other which
can be programmed.
AUTOMATIC VERSION
The additional heater is turned on in
automatic mode when the engine
is started and the required outside
temperature and coolant conditions are
present. Deactivation is always
automatic.
21)
IMPORTANT During periods with low
outdoor temperatures when the device
cuts in, check that the fuel level is
always higher than the reserve level.
Otherwise the device could lock and
require the assistance of a Fiat
Dealership.
PROGRAMMABLE
VERSION
The additional heater operates
completely independently of engine
operation and allows the following:
❒ heating the passenger compartment
with the engine off
❒ defrosting the windows;
❒ heat the engine coolant and then the
engine itself prior to starting.
The system consists of:
❒ a diesel burner for heating the water
with an exhaust silencer for the
combustion gases;
❒ a metering pump connected to the
reservoir pipes for supplying the
burner;
❒ a heat exchanger connected to the
engine cooling system pipes;
❒ a control unit connected to the
passenger compartment
heating/ventilation system to allow
automatic operation;
❒ an electronic control unit for
controlling and adjusting the built-in
burner;
❒ a digital timer fig. 54 for turning the
heater on manually or for
programming the time that it comes
on.
MODE
F
53
F1A0305
41
