4 SPECIFICATIONS
4.1 GENERAL
Specification
FLEX-6400
FLEX-6600
Frequency Range (Transmitter)
• Rated Output Power @ 100W
nominal
160m - 6m (Amateur bands
only by country) MARS
optional
160m - 6m (Amateur bands
only by country) MARS
optional
• Transverter (XVTR) IF Output Port
100 KHz - 54 MHz
100 KHz – 54 MHz
Frequency Range (Receiver)
• Low Band (First Nyquist Zone)
30 kHz – 54 MHz
30 KHz to 54 MHz
• High Band (Second Nyquist Zone)
NA
NA
Emission Modes*
A1A (CW), A3E(AM), J3E (SSB),
F3E (FM)
A1A (CW), A3E(AM), J3E (SSB),
F3E (FM)
Frequency Stability
• Standard
0.5ppm TCXO
0.5 ppm TCXO
• With GPSDO Option (GPS Locked)
5x10
-12
over 24 Hours
5x10
-12
over 24 Hours
Antenna Impedance - Unbalanced
50 Ohms
50 Ohms
Antenna Tuner Load Range - Unbalanced
8.3 - 300 Ohms (80m – 10m)
6.7 - 150 Ohms (160m and 6m)
8.3 - 300 Ohms (80m – 10m)
6.7 - 150 Ohms (160m and 6m)
Standard Supply Voltage
+13.8 VDC +/- 15%
+13.8 VDC +/- 15%
Supply Current (Receive/Transmit)
1.7A Receive Typ., 23A
Transmit Max.
2A Receive Typ., 23A Transmit
Max.
Operating Temperature Range
0 to +50C, +32 to +122F
0 to +50C, +32 to +122F
Dimensions
• With Feet
7” (17.8 cm) H, 14” (35.5 cm)
W, 12” (30.5 cm) D
7” (17.8 cm) H, 14” (35.5 cm)
W, 12” (30.5 cm) D
• Weight
10.5 lbs., 4.8 kgs
11.1 lbs, 5.0 kgs
* - Other modes may be available through the addition of third-party waveform plug-ins.
4.2 TRANSMITTER
Specification
FLEX-6400
FLEX-6600
Transmitter Architecture
Direct Digital Up Conversion
Direct Digital Up Conversion
TX DAC Resolution
16-bit
16-bit
TX DAC Sampling Rate
122.88 Msps
245.76 Msps
Output Power CW/SSB/RTTY/FM (AM) at
13.8 VDC (nominal)
100W (25W)
100W (25W)
XVTR Port Power Output
0 dBm Typ.,
+10 dBm Max.
0 dBm Typ.,
+10 dBm Max.
Modulation
DSP Generation
DSP Generation
Spurious Emissions
HF: -55 dBc, 6m: -65 dBc
HF: -55 dBc, 6m: -65 dBc
Carrier Suppression
-80 dBc below peak output
-80 dBc below peak output
Unwanted Sideband Suppression
-80 dBc below peak output
-80 dBc below peak output
Transmit Frequency Response
Default 100-2900 Hz (Variable
50-10 kHz)
Default 100-2900 Hz (Variable
50-10 kHz)
Microphone Impedance
600 Ohms Nominal, 200-10k
Ohm
600 Ohms Nominal, 200-10k
Ohm
