IDENTIFYING
COMPONENTS
IN
THE
ENGINE
COMPARTMENT
3.5L
V6
engine
1.
Engine
coolant
reservoir
2.
Power
steering
fluid
reservoir
3.
Brake
fluid
reservoir
4.
Battery
5.
Power
distribution
box
6.
Air
filter
assembly
7.
T
ransaxle
fluid
dipstick
8.
Engine
oil
dipstick
9.
Engine
oil
filler
cap
10.
W
indshield
washer
fluid
reservoir
2008
Edge
(edg)
Owners
Guide
(post-2002-fmt)
USA
(fus)
Maintenance
and
Specifications
294
293
295
