ENGINE
DATA
Engine
3.5L-DOHC
V6
engine
Displacement
3.5L
Required
fuel
87
octane
Firing
order
1–4–2–5–3–6
Spark
plug
gap
(0.052–0.056
inch)
1.32–1.42
mm
Ignition
system
Coil
on
plug
Compression
ratio
10.3:1
Engine
drivebelt
routing
•
3.5L
V6
Engine
1.
Short
drivebelt
is
on
first
pulley
groove
closest
to
engine.
2.
Long
drivebelt
is
on
second
pulley
groove
farthest
from
engine.
2008
Edge
(edg)
Owners
Guide
(post-2002-fmt)
USA
(fus)
Maintenance
and
Specifications
326
325
327
