RAISING THE CAR
If the car is to be lifted, go to a Ford
Dealership which is equipped with the
arm hoist or workshop lift.
fig. 37
KA00076m
Before towing, turn the
ignition key to MAR-ON
and then to STOP without
removing it. The steering column
will automatically lock when the
key is removed and the wheels
cannot be steered.
WARNING
TOWING THE CAR
The tow ring, which is provided with
the car, is housed in the tool box,
under the boot mat.
TOW RING HOOKING fig. 37
Proceed as follows:
❒
release the cap A;
❒
take the tow ring B from its seat
in the tool support;
❒
fully tighten the ring on the
front threaded pin.
