37
SAFETY
STARTING
AND DRIVING
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
SERVICING
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
KNOWING
YOUR CAR
HIGH BEAMS fig. 30
With knurled ring in position
2
, push
the stalk forward toward the dashboard
(steady position). The warning light
1
on the instrument panel will come on.
Pulling the stalk towards the steering
wheel, the high beams are turned off and
the low beams on.
FLASHING fig. 30
You can flash the beams pulling the stalk
toward the steering wheel (unstable
position). The warning light
1
on the
instrument panel will come on.
DIRECTION INDICATORS fig. 31
Place the lever in the (stable) position:
up (position a): activates the right
direction indicator;
down (position b): activates the left
direction indicator.
The warning light ¥ or Î flash on the
instrument panel.
Indicators are switched off automatically
when the steering wheel is straightened.
Lane change function
If you wish to signal a lane change, place
the left lever in the unstable position
for less than half a second. The direction
indicator on the selected side flashes
three times and then switches off
automatically.
EXTERNAL LIGHTS
The left-hand stalk operates most of the
external lights. The external lights can
only be switched on when the ignition
key is on MAR-ON. The instrument
panel and the various dashboard
controls will come on with
the external lights.
Lights off fig. 30
Ring nut turned to position
O
.
SIDE LIGHTS fig. 30
Turn the ring nut to position
6
.
The warning light
3
on the
instrument panel comes on.
DIPPED BEAMS fig. 30
Turn the ring nut to position
2
.
The warning light
3
in the instrument
panel comes on.
fig. 30
KA00108m
fig. 31
KA00109m
026-046 Ford KA EN 08/04/14 08:36 Pagina 37
