E131643
Loa
d Rating of T
ype 1 Tie Do
wn Point
s:
300 kg.
Type 2
W
ARNING
Do not ex
ceed the l
oad r
ating f
or the
tie down points.
E133894
Loa
d Rating of T
ype 2 Tie Do
wn Point
s:
200 kg.
Type 3
W
ARNING
Do not ex
ceed the l
oad r
ating f
or the
tie down points.
E133896
A
B
C
D
E134098
Cle
at.
A
Bezel.
B
Spring.
C
Pin.
D
Do not use the tie down points under the
foll
owing c
onditions:
•
Any sign of we
ar or damage
.
•
Rail channels supporting the tie do
wn
points show an
y sign of wear
, damage
or distortion.
168
Ranger (), EB3B-19G219-ZAB enA
US
Load Carrying
169
171
