5-8 Fresenius Medical Care 4008 4/08.03 (TM)
䊱䊲
䊱䊲
䊱䊲
䊱䊲
䊱䊲
䊱䊲
䊱䊲
䊱䊲
䊱䊲
䊱䊲
䊱䊲
䊱䊲
䊲
䊲
I: CPU1_BLL_DIM
Blood leak dimness voltage
5.0 V, IC 28/2, ADC 108
I: CPU1_BLL
Blood leak voltage
5.0 V, IC 28/3, ADC 108
I: CPU1_COND_SIGNAL1
CD display
0 to 10.8 V, IC 28/4, ADC 0 to 231
I: CPU1_REF2
Reference voltage AD1
2.5 V, IC 28/5, ADC 128
(2.3 V to 2.5 V)
I: CPU1_FREE1
Not used
0 V, IC 29/26, ADC 0
I: CPU1_TEMP_DIAL2
Temperature NTC 109
0 to 12 V, IC 29/27, ADC 0 to 255
I: CPU1_COND_SINGAL2
Not used
0 V, IC 29/28, ADC 0
I: CPU1_COND_SIGNAL3
CD cell (slot X108 / LP 747)
0 – 10,8 V, IC 29/2, ADC 0 – 231
I: CPU1_FREE2
Not used, open input
IC 29/3
I: CPU1_U_BATT_SW
Voltage for alarm tone, if battery relay
is off
10.6 V, IC 29/4, ADC 110
I: CPU1_REF3
Reference voltage AD2
2.5 V, IC 29/5, ADC 128
(2.3 to 2.5 V)
back to menu ?
Confirm
key
CPU1: RD ANALOG INP.
䊱䊲
I: CPU1_P_ART
Arterial pressure
0 to 10.5 V, IC 28/1, ADC 0 to 225
䊱䊲
I: CPU1_TEMP_DIAL3
Temperature NTC
(slot X107 / LP 747)
0 – 12 V, IC 29/1, ADC 0 – 255
