TECHNICAL DATA
MW 2600 MW 2600CEL MW 3000 MW3000
Mains voltage +15 / -20%, 50-60 Hz 3x400 V 3x400 V 3x220 V 3x400 V
Mains fuse protection (slow-blow) 16 A 16 A 20 A 16 A
Apparent power at 35 % d.c. --- --- 9,7 kVA ---
40 % d.c. --- 15,7 kVA --- ---
50 % d.c. 11,1 kVA --- --- ---
60 % d.c. 10,6 kVA 10,4 kVA 6,1 kVA ---
65 % d.c. --- --- --- 11,8 kVA
100 % d.c. 8,1 kVA 8,1 kVA 4,6 kVA 9,7 kVA
Cos phi
1
150 A 0,99 0,99 0,99 0,99
260 A 0,99 0,99 --- ---
300 A --- --- 0,99 0,99
Efficiency 86 % 83 % 83 % 85 %
Welding current range DC 3-260 A 3-260 A 3-300 A 3-300 A
AC 5-260 A 5-260 A 5-300 A 5-300 A
Welding current 35 % d.c. --- --- 300 A ---
(duty cycle: 40 % d.c. --- 260A --- ---
10min at +40°C) 50 % d.c. 260 A --- --- ---
60 % d.c. 240 A 180A 220 A ---
65 % d.c. --- --- --- 300 A
100 % d.c. 185 A 145 A 170 A 260 A
Operating voltage TIG 10,1-20,4 V 10,1-30,4 V 10,1-22,0 V 10,1-22,0 V
standardized Electrode 20,1-30,4 V 20,1-30,4 V 20,1-32,0 V 20,1-32,0 V
Operating voltage max. 40V 48V 42V 38V
Open circuit voltage 83 V DC 83 V DC 83 V DC 83 V DC
Insulation category F F F F
Degree of protection IP 23 IP 23 IP 23 IP 23
Type of cooling AF AF AF AF
Weight (without cooling unit) 73 lb 66 lb 75 lb 75 lb
Approval marks
CE
CE
CECE
TT 2600 TT 2600CEL TT 3000 TT3000
Mains voltage +15 / -20%, 50-60 Hz 3x400 V 3x400 V 3x220 V 3x400 V
Mains fuse protection (slow-blow) 16 A 16 A 20 A 16 A
Apparent power at 35 % d.c. --- --- 9,7 kVA ---
40 % d.c. --- --- --- ---
60 % d.c. 10,5 kVA 10,7 kVA 6,1 kVA ---
65 % d.c. --- --- --- 11,8 kVA
100 % d.c. 8,4 kVA 9,2 kVA 4,6 kVA 9,7 kVA
Cos phi
1
150 A 0,99 0,99 0,99 0,99
260 A 0,99 0,99 --- ---
300 A --- --- 0,99 0,99
Efficiency 86 % 89 % 85 % 89 %
Welding current range DC 3-260 A 3-260 A 3-300 A 3-300 A
AC --- --- --- ---
Welding current 35 % d.c. --- --- 300 A ---
(duty cycle: 40 % d.c. --- --- --- ---
10min at +40°C) 60 % d.c. 260 A 260 A 220 A ---
65 % d.c. --- --- --- 300 A
100 % d.c. 220 A 230 A 170 A 260 A
Operating voltage TIG 10,1-20,4 V 10,1-20,4 V 10,1-22,0 V 10,1-22,0 V
standardized Electrode 20,1-30,4 V 20,1-30,4 V 20,1-32,0 V 20,1-32,0 V
Operating voltage max. 38V 65V 42V 38V
Open circuit voltage 83 V DC 80 V DC 83 V DC 83 V DC
Insulation category F F F F
Degree of protection IP 23 IP 23 IP 23 IP 23
Type of cooling AF AF AF AF
Weight (without cooling unit) 62 lb 62 lb 62 lb 62 lb
Approval marks
CECECE CE
