FS S3200 Series User Manual

1. Plug the compatible SFP/SFP+ optical module into the SFP/SFP+ port.
2. Connect one end of a fiber optic cable to the optical module. Then connect the other end of the
cable to another fiber device.
1. Insert the RJ45 connector of the console cable into the console port of the switch.
2. Connect the DB9 female connector of the console cable to the serial port of the computer.
Connecting the CONSOLE Port
WARNING: Laser beams will cause eye damage. Do not look into bores of optical modules or
fiber optical cables without eye protection.
Configuring the Switch
Configuring the Switch via the Web-based Interface
Step 1: Connect the computer to the Management port of the switch using the network cable.
Step 2: Set the IP address of the computer to 192.168.1.x.(“x” is any number from 2 to 254.)
EN
9
Left LED: Link/Act Mode Right LED: PoE Mode
SYS
PWR
PoE
CONSOLE
S3200-8M4GS-U
PoE+
1 2 3 4
1 2 3 4

FS S3200 Series Specifications

General

Series	S3200 Series
Managed	Yes
MAC Address Table Size	16K
Type	Switch
Uplink Ports	2/4 x 10GE SFP+
Forwarding Rate	95.2 Mpps
Jumbo Frame Support	9K
Management	Web, CLI, SNMP
Power Supply	AC 100-240V
Weight	4.5 kg
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions (W x D x H)	440 x 200 x 44 mm (17.3 x 7.9 x 1.7 in)
