Fujitsu AB12 User Manual

Ref Parts No. Ord Ref Parts No. Ord
No. AOY90TPAMF Q'ty No. AOY90TPAMF Q'ty
333 ACCUMLATOR ASSY 9366351009 765 DRAIN PIPE.( I-TYPE ) 9301102000
867 ACCUMULTR HLD.RUBBER 9354022027 15 DRYER 9361926004
833 AUXILIARY PIPE ASSY 9363891003 829-16 DRYER JNT PP ASSY 9363893007
196-1 BAINDER XL 9366156000 4 EMBLEM-REAR 9359836018
452 BAL VLV JNT PIPE C 9363900002 629 EMI FILTER 0400056133
121 BALL VALVE JOINT B 9365533000 629 EMI FILTER 0400056140
809 BALL VALVE-A 9361937000 EMI FILTER 0400165040
810 BALL VALVE-B 9361938007 825-1 EXPANSION VALVE 9361929005
810-1 BALL VALVE-B 9362579001 825-2 EXPANSION VALVE 9363294002
12 BASE ASSY 9361684003 825 EXPANSION VALVE ASSY 9366067009
100 BASE FOOT 9361688025 2 FAN COVER 9366142010
477 BELL-MOUTH 9361721005 41 FAN MOTOR ASSY-OUTER 9601271017
790-3 BELT HEATER 9361140073 560 FLANGE ASSY 9363035001
790-1 BELT HEATER-A 9361140042 964 FLARE NYT 9363273007
790-2 BELT HEATER-B 9361140059 133 FRONT PANEL-L 9361709027
674 BOLT 0700145100 63-1 FRONT PANEL-L 9361709010
653 BOLT, FOR FAN MOTOR 0700145087 134 FRONT PANEL-R 9361710047
69-3 BOLT, HEX. SOCKET 301210060360 63-2 FRONT PANEL-R 9361710030
966 BONNET 9363274004 132 FRONT PROTECTION NET 9366144014
199 BR SHEET 9363708028 824-3 FUSE 0600222574
220-1 BR SHEET-B 9351990022 FUSE HOLDER 0500158072
42 BRACKET PANEL ( MOTOR ) 9361703001 761 GAS FQUALIZATION ASY 9365721001
87 BRACKET ( COMPRESSOR ) 9361694002 86 GASKET 9363272000
355 BRACKET ( COMPRESSOR )-L 9361698000 150 HALF UNION-B 9357351018
356 BRACKET ( COMPRESSOR )-R 9361699007 HEAT SINK 9703347016
376 BRACKET ( CONTROL BOX ) 9361727007 HYBRID IC 0100335019
45 BRACKET ( MOTOR ) 9361701007 IC 0101461120
678 BRACKET ( THERMISTOR ) 313557406106 IC 0101547039
176 BRACKET ( VALVE )-A 9361719002 IC LIN 0100462098
890 BRKT PNL ( COMP ) ASSY 9364208008 IC ( TRANSISTOR ASSY ) 0100028041
175 BRKT PNL ( S VLV ) 9364230009 285 INSU ( ACCUMLATOR ) 9366131007
361 BUSHING 9361725003 267 INSULATION ( PIPE )-C 313005074759
564 BYPASS A ASSY 9366164005 829-1 JOINT PIPE A ASSY 9363994001
564-1 BYPASS B ASSY 9366165002 829-7 JOINT PIPE F ASSY 9363912005
564-2 BYPASS C ASSY 9366166009 829-8 JOINT PIPE G ASSY 9364022000
654-3 BYPASS D ASSY 9366928003 829-9 JOINT PIPE H ASSY 9364017006
64/34 CAPACITOR ( FAN MOTOR ) 9703306037 829-15 JOINT PIPE K 9364959009
CAPACITOR . ELEC 0301192558 829-14 JOINT PIPE I 9365016008
CAPACITOR . ELEC 0300256060 829-13 JOINT PIPE M 9365017005
CAPACITOR . ELEC 0301192589 829-2 JOINT PIPE ( SUB COOL ) 9365858004
CAPACITOR . ELEC 0301196822 LABEL."R407C" 9362389006
CAPACITOR.PLASTIC 0300304099 LED 0000813259
CAPACITOR.PLASTIC 0301052098 381-2 LOCKING SPACER 0600035020
178-2 CAPILLARY HLD.RUBBER 313394274808 381-3 LOCKING SPACER 0600118051
CERAMIC RESONETOR 9701261031 791 MAGNETIC RELAY 9363277005
519-2 CHECK VALVE 9353020000 MANUAL ( INSULATION ) 9367724017
187 CLAMP 313361271706 880-1 NETWORK ( C-R ) 9700987017
182 CLAMP 313361271505 NETWORK ( CR ) 9701125012
195 CLAMP 313361275805 347 NOISE INSULATION-D 313712304109
196-2 CLAMP 313035356905 761-1 OIL EQUALZATION 9366275008
196-1 CLAMP 312300787605 914 OIL SENSOR ASSY 9365712009
407 CLAMP 313739340109 331 OIL SEPA JNT PP A AS 9363944006
919-3 COIL ( EXPANSION VALVE ) 9361930001 914-1 OIL SEPARATOR A ASSY 9366359005
919-1 COIL ( EXPANSION VALVE ) 9366344001 915 OIL SEPARATOR B ASSY 9366368007
919-2 COIL ( EXPANSION VALVE ) 9366345008 PACK ING BOTTOM PAPER 9363888003
46-1 COMPRESSOR ASSY 9367379002 PACKING CASE-CARTON 9301094015
46-2 COMPRESSOR ASSY 9367380008 PACKING WOOD-BOTTOM 9362978019
46-3 COMPRESSOR ASSY 9367381005 PACKING WOOD-FRONT 9362979016
310 COMPRESSOR COVER 9366132004 PACKING WOOD-PROTECT 9363301014
26 COMPRESSOR COVER-A 9361935006 PACKING WOOD-SIDE 9362980012
646 COMPRESSOR COVER-B 9361936003 PACKING WOOD-TOP 9362981019
149-1 CONDENCING PIPE F AS 9365439005 PHOTO COUPLER 0000117074
149 CONDENCING PIPE P AS 9364952000 172 PIPE COVER 9363470000
16-1 CONDENSER A ASSY 9365462003 172-1 PIPE COVER B 9366129004
16-2 CONDENSOR B ASSY 9365463000 PLUG.PWB 0500005338
527 CONDENSER GUARD 9366143017 PLUG.PWB 0500006069
158 CONNECTING PIPE ASSY 9366491002 PLUG.PWB 0500011131
32 CONTROL BOX 9361713000 PLUG.PWB 0500011155
942 CONTROL BOX COVER 9361716001 PLUG.PWB 0500011520
236 CONTROLLER PCB ASSY 9703739019 PLUG.PWB 0500011766
982-1 CORD CLAMP 9356857009 PLUG.PWB 0500011773
982-2 CORD CLAMP-B 9356858006 PLUG.PWB 0500011803
193 CUSHION RUBBER 313376149201 PLUG.PWB 0500011810
450 DICHARG PIPE A ASSY 9363996005 PLUG.PWB 0500011827
493 DICHARG PIPE C ASSY 9363909005 PLUG.PWB 0501045012
DIODE 0000353120 PLUG.PWB 0501045029
DIODE 0000625036 PLUG.PWB 0501045050
DIODE 0000746519 PLUG.PWB 0501045098
DIODE 0000906500 PLUG.PWB 0501045210
DIODE.MINIMOLD 0000684019 PLUG.PWB 0501045227
DIODE.POWER 0000208024 PLUG.PWB 0501045319
DIODE.POWER 0000689045 PLUG.PWB 0501045357
160 DRAIN PAN 9361700000 PLUG.PWB 0501045418
Description Description
– 173 –
11. PARTS LIST
AOY90TPAMF
Models :
OUTDOOR UNIT

Fujitsu AB12 Specifications

General

Brand	Fujitsu
Model	AB12
Category	Air Conditioner
Language	English
