4-4 FUNCTION AND SETTING OF EACH SWITCH
1. DIP SWITCH 1
Ceiling height setting.
Changeover the fan speed of the indoor fan phase control according to ceiling height (cassette type).
Details of rotation is according to DIP SW3 setting.
CEILING HEIGHT SETTING 1,2
Standard High ceiling 1 Low ceiling
OFF
HIGH(1)
ON
Room temp correct coefficient of heating.
Decide room temp correct coefficient value of heating.
Room temp. correct coefficient of cooling.
Decide room temp correct coefficient value of cooling.
1
■ INDOOR UNIT
2
1
SW1-1
SW1-2
High ceiling 2
HIGH HIGH
HIGH
ON ON
ON
OFF OFF
OFF
MED MED
MED
MEDLOW
LOW LOW
S-LOW S-LOW S-LOW S-LOW
LOW
(2)
(3)
(4)
(5)
(6)
ROOM TEMP. CORRECT COEFFICIENT OF HEATING
Coefficient value
OFF
ON
+ 2 deg
SW1-3
SW1-4
0 degOFF
ON OFF - 2 deg
OFF
+ 4 degON ON
2. DIP SWITCH 2
ROOM TEMP CORRECT COEFFICIENT OF COOLING
Coefficient value
0 deg
SW2-1
ON + 2 deg
OFF
Zone control switch.
Decide the indoor unit for zone control use and not for zone control.
2
NOTCH
ZONE CONTROL SWITCH
Switch control
Validity
SW2-2
ON
Invalidity
OFF
Ceiling height
2.5 3.0m
3.0 3.5m
more than
3.5m
less than
2.5m
