Fujitsu Airstage VR-II ARUM36TLAV User Manual

Model : AJUA72_96TLBV (S chassis)
AJUA120TLBV (L chassis)
WARNING
Before servicing the unit, turn the power supply switch OFF,
Then, do not touch electric parts for 10 minutes due to the risk of electric shock.
1. Appearance
2. PANEL TOP removal
3. CONTROL BOX COVER removal
screws
screws
Hook (3 places)
Remove the 4 mounting screws. Remove the PANEL TOP
by sliding toward.
Remove the 4 mounting screws. Remove the CONTROL BOX COVER
by sliding toward.
