9. TIMER OPERATION CONTROL

1. ON / OFF TIMER

OFF timer : When the clock reaches the set time, the air conditioner will be turned off.

Operation mode

Stop mode

Set time of timer

ON timer : When the clock reaches the set time, the air conditioner will be turned on.

Operation mode

Stop mode

Set time of timer

2. PROGRAM TIMER

01-11

AR- JW5

9-1 Wireless Remote Controller (accessory parts)

ON / TIMER

OFF / TIMER

PROGRAM TIMER

SLEEP TIMER

The program timer allows the OFF timer and ON timer to be used in combination one time.

Operation mode

Operation will start from the timer setting (either OFF timer or ON timer)

whichever is closest to the clock's current timer setting.

The order of operations is indicated by the arrow in the remote control unit's display.

SLEEP timer operation cannot be combined with ON timer operation.

Stop mode

Operation mode

Set time

Set time Set time Set time
