7. TIMER OPEARTION CONTROL
1. ON / OFF TIMER
The Table 10 shows the available timer setting based on the product model.
OFF timer : When the clock reaches the set time, the air conditioner will be turned off.
Operation mode
Stop mode
ON timer : When the clock reaches the set time, the air conditioner will be turned on.
Operation mode
Stop mode
The program timer allows the OFF timer and ON timer to be used in combination one time.
Operation mode
Operation will start from the timer setting (either OFF timer or ON timer) whichever is closest
to the clock's current timer setting.
The order of operations is indicated by the arrow in the remote control unit's display.
SLEEP timer operation cannot be combined with ON timer operation.
2. PROGRAM TIMER
Stop mode
7-1 WIRELESS REMOTE CONTROLLER
( Table 10 : Timer setting )
ON TIMER / OFF TIMER PROGRAM TIMER SLEEP TIMER
Set timeSet timeSet timeSet time
Operation mode
Operation mode
Stop mode
Stop mode
Set time of timer
Set time of timer
01-16
