Fujitsu ASY50-KM Design & Technical Manual

1-1. Indoor unit connection patterns
¢ 4-unit multi-split type
AOYG30KBTA4
Combination no. Unit 1 Unit 2 Unit 3 Unit 4 Total
1 7 22 — — 29
2 7 24 — — 31
3 9 22 — — 31
4 9 24 — — 33
5 12 18 — — 30
6 12 22 — — 34
7 12 24 — — 36
8 14 18 — — 32
9 14 22 — — 36
10 14 24 — — 38
11 18 18 — — 36
12 18 22 — — 40
13 18 24 — — 42
14 22 22 — — 44
15 22 24 — — 46
16 24 24 — — 48
17 7 7 12 — 26
18 7 7 14 — 28
19 7 7 18 — 32
20 7 7 22 — 36
21 7 7 24 — 38
22 7 9 9 — 25
23 7 9 12 — 28
24 7 9 14 — 30
25 7 9 18 — 34
26 7 9 22 — 38
27 7 9 24 — 40
28 7 12 12 — 31
29 7 12 14 — 33
30 7 12 18 — 37
31 7 12 22 — 41
32 7 12 24 — 43
33 7 14 14 — 35
34 7 14 18 — 39
35 7 14 22 — 43
36 7 14 24 — 45
37 7 18 18 — 43
38 7 18 22 — 47
39 7 18 24 — 49
40 9 9 9 — 27
41 9 9 12 — 30
42 9 9 14 — 32
43 9 9 18 — 36
44 9 9 22 — 40
45 9 9 24 — 42
46 9 12 12 — 33
47 9 12 14 — 35
48 9 12 18 — 39
49 9 12 22 — 43
50 9 12 24 — 45
- 4 -
1-1. Indoor unit connection patterns
1. Model lineup
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE
