Fujitsu B22W-6 LED User Manual

Operation
Adjusting the brightness and contrast
Call up the Brightness/Contrast setting window
Brightness
Set the brightness of the d isplay
With this function yo u can change the brightness of the background lighting.
Contrast
Set the contrast of the display
With this function you c an modify the contrast of pale colours.
Black level
Set the brightness of the d isplay
With this funct ion you modify the contrast of dark colours.
Auto level
Adjust the signal level
With this function you can automatically set the contrast.
Thefunctionisexecutedwiththe
button.
If the contrast is set too high, bright surfaces can no longer be d istinguished from very
bright surfaces. If the contrast is set too low, the maximu m brightness will not be achieved.
Adjusting the picture size and position
Call the Image ad
just setting window
Phase
Eliminate picture disturbance
With this function you fin e-tune your mo nitor to eliminate picture disturbance.
Clock
Set synchroni
sation
With this fun
ction you adjust the picture width t o eliminate vertical picture
disturbance
s.
H-Position
Adjust the h
orizontal position
With th is f
unction you move the p icture to the left or to the right.
V-Positio
n
Adjust th
e v ertical position
With this
function you move the picture up or down.
Expansi
on
Adjust t
he picture s ize
Full scr
een = selection of full screen mode
Keep as
pect = maximum picture size without distortion (only for PC image)
16:9 =
16:9 widescreen format (Video/TV picture only)
4:3 =4
:3 format (Video/TV picture only)
26 Fujitsu Technology Solutions
Downloaded from ManualMonitor.com Manuals

Fujitsu B22W-6 LED Specifications

General

3D	No
HD type	-
Pixel pitch	0.282 x 0.282 mm
Aspect ratio	16:10
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Viewable size diagonal	559 mm
Viewable size, vertical	296 mm
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	474 mm
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	30 - 82 kHz
Display brightness (typical)	250 cd/m²
Power requirements	AC 100V - 240V@50-60Hz, AC/DC
Mean time between failures (MTBF)	70000 h
HDCP	Yes
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	5
RMS rated power	2 W
Number of speakers	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	28 W
Power consumption (PowerSave)	0.3 W
Certification	CE, TÜV GS, GOST, FCC B, cUL, TCO Displays 5.0, ENERGY STAR 5.0
Product color	White
Pivot angle	0 - 90 °
Tilt angle range	-5 - 35 °
Height adjustment	110 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POL, POR, RUS, SWE, TUR
Package weight	8900 g

Weight and Dimensions

Depth (with stand)	180 mm
Height (with stand)	370 mm
Weight (with stand)	7100 g
Depth (without stand)	60 mm
Width (without stand)	508 mm
Height (without stand)	343 mm
Weight (without stand)	4200 g
