A-2.
Cutter Specifications
Cutting method: Partial cut (the paper remains connected at one point)
Partial/full cutting (factory-installed option)
(A command for switching between partial cutting
and full cutting is provided for models that support
these two cutting methods.)
Caution: The maximum number of successive cuts by the cutter is 30 cuts
per minute (at least two seconds per cut). Using the cutter at a
higher rate may cause a failure.
Caution: For printing on label paper, use only partial cutting. If full cutting
is used in such cases, paper cutting performance will deteriorate
faster because of the greater adverse effect of adhesive matter.
Caution: Paper cutting performance may deteriorate faster with the use of
label paper because of its adhesive matter. Clean the cutter blade
periodically to remove the adhesive matter.
Caution: Full cutting may lead to irregularities at the center of the cutting
surface. If paper fiber remains at these locations, this may
eventually lead to incomplete cutting at these locations.
Caution: In full cutting mode, the printed paper must be removed each time
that one sheet is printed. Otherwise, printed paper remains in the
automatic cutter section and may cause a cutting error.
A-3.Paper Supply Specifications
(1) Loading method: Rolls are loaded manually.
(2) Paper near end: Detected when only a little paper is left.
Caution: This printer supports paper rolls with a core diameter of φ18mm.
If a heavy-paper roll with a core diameter of φ32mm is used, paper
near end cannot be detected.
A-4.Interface Specifications
(1) RS-232C
(2) Parallel (Complies with IEEE1284: Nibble mode)
(3) USB (Conforms to USB 2.0 Full Speed)
(4) Powered USB
(5) Dual (Conforms to USB 1.1 and RS-232C)
(6) LAN (10BASE-T,100BASE-TX)
(7) Bluetooth (Compliant with standard specification v3.0)
