Appendix B: Interface
B-1.Serial Interface
(1) Specifications of transmission interface
Transmission method
Asynchronous
Line type
Full duplex
Input/output circuits
Input: Equivalent to MAX211
Output: Equivalent to MAX211
Baud rate
2400, 4800, 9600, 19200, 38400, 57600, 115200 BPS
(depending on the setup specifications)
Transmission code type
7-bit or 8-bit code
Transmission code
format
Start bit length: 1 bit, SUpper bit length: 1 bit
Data bit length: 7 or 8 bits (specified at setup)
Parity bit: NONE, ODD, EVEN (specified at setup)
Mark (1)
ST b0 b1 b2 b3 b4 b5 b6 b7 PT SP
Space (0)
Transmission sequence
LSB first system
Transmission code
system
JIS code
Error control
Parity check (specified at setup)
Maximum connection
line length
15m (for power supplied via AC adapter) or 2m (for
power supplied via interface connector)
Protocol
DSR/DTR, XON/XOFF (specified at setup)
